數字孿生管理系統是基于亞洲首個300米深水導管架“?；惶?rdquo;建造的。通過智能傳感和數字孿生技術的集成，該系統連接了一個虛擬和一個真實的兩個強大平臺，這兩個平臺協同工作，實現了水下結構的全面數據捕獲、安全管理的遠程控制和智能風險預警能力。該系統是中國海上油氣數字化轉型的典范，突顯了中國在技術創新方面取得的巨大進步。經過40周的穩定測試運行，該系統收集了大量數據，數據量幾乎達到2TB。在此期間，該系統經受了多個臺風的考驗，并成功地從“Ma on”、“NESAT”和“Nalgae”三個特定臺風中獲得了寶貴的數據，進一步鞏固了其作為一個強大可靠系統的聲譽。
本項目開發的導管架數字孿生軟件系統融合了綜合數據管理、監測、預警、檢測、評估和數字孿生等多種功能。這一尖端系統能夠?qū)崟r監控和顯示平臺數據。通過不斷積累監測數據和迭代更新數據庫，系統對導管架進行實時分析和智能數據采集。在真實導管架和常規評估計算的支持下，該平臺建立了一種可靠的方法來評估局部風險狀態。
此外，該管理系統實現了在線操作和維護管理，為優化深水導管架的未來設計和規格鋪平了道路。
Recently, COOEC has taken a crucial step forward in the field of deep-water digital twins with the formal operation of the world’s first digital twin management platform of deep-water jacket. The significance of this self-developed platform also lies in its ability to enhance the intelligent risk early-warning and life-cycle operation and maintenance management of deep-sea oil and gas equipment.
The digital twin management system is built based on the 300-meter deep-water jacket "Haiji-1" ，which is the first of its kind in Asia. Through the integration of intelligent sensing and digital twin technology, the system connects two powerful platforms ，one virtual and one real ，that work in unison to enable comprehensive data capture of underwater structures, remote control of safety management, and intelligent risk-warning capabilities. The system serves as an exemplar for China's offshore oil and gas digital transformation, highlighting the country's impressive strides in technological innovation. After 40 weeks of stable test operation, the system has collected an impressive volume of data amounting to almost 2TB. The system has endured many typhoons during this period and has successfully obtained valuable data from three specific typhoons, namely "Ma-on", "NESAT", and "Nalgae", further cementing its reputation as a robust and reliable system.
The jacket digital twin software system developed in this project incorporates multiple functions, such as integrated data management, monitoring, early warning, detection, evaluation, and digital twin. This cutting-edge system enables real-time monitoring and display of platform data. By continuously accumulating monitoring data and updating the database iteratively, the system performs real-time analysis and intelligent data capture of the jacket. With the support of the real jacket and routine assessment calculations, the platform has established a reliable method to evaluate the local risk status.
Additionally, the management system enables online operation and maintenance management, paving the way for optimizing future design and specification of deep-water jackets.
